Product Name:
1w high power led white General Specifics:
1, 1w pure white led 2, 5700-6300K CCT
3, 3.0-3.4v
4, Epistar,Eileds etc chip taiwan
5, 3 year warranty
1w led pure white 90-100lm 5700-6300k steady quality very good price
Product Details:
,1w pure white led2, 5700-6300K CCT
3, 3.0-3.4v
4, Epistar,Eileds etc chip taiwan
5, 3 year warranty
| Model | Emitting color | Wavelength / CCT | Typical Lumens | Forward voltage | Forward current | Viewing angle |
| Tresun have large stock for 1W white led, 300K can ship within 2 days | ||||||
| TS-1WR030140D | Red | 625±5nm | 40-60lm | 2.0-2.5v | 350-700mA | 140° |
| TS-1WY035140D | Yellow | 590±5nm | 50-70lm | 2.0-2.5v | 350-700mA | 140° |
| TS-1WB035140D | Blue | 460±5nm | 25-35lm | 2.0-2.5v | 350-700mA | 140° |
| TS-1WG035140D | Green | 525±5nm | 50-80lm | 2.0-2.5v | 350-700mA | 140° |
| TS-1WP035140D | White | 5700-7300K | 90-110lm | 3.0-3.5v | 350mA | 140° |
| TS-1WW035140D | Warmwhite | 2700-3500K | 90-110lm | 3.0-3.5v | 350mA | 140° |
Standard type Eletctronical / Optical Characteristics(at Ta=25ºC)
| Part number | Emitting color | CCT | Forward voltage | Forward current | Typical Lumens |
| TS-1WP035140D-A1 | White | 6000-7000K | 3.0-3.4v | 350mA | 80-90lm |
| TS-1WP035140D-A2 | White | 6000-7000K | 3.0-3.4v | 350mA | 90-100lm |
| TS-1WP035140D-A3 | White | 6000-7000K | 3.0-3.4v | 350mA | 100-110lm |
| TS-1WP035140D-A4 | White | 6000-7000K | 3.0-3.4v | 350mA | 110-120lm |
| TS-1WP035140D-A5 | White | 6000-7000K | 3.0-3.4v | 350mA | 120-130lm |
