Product Name:
Super bright bluet shape mcd 25000~28000 Water Clear 5mm led diodes red General Specifics:
water clearlow power consumption
long life
Product Details:
5mm leds water clear lense red
Features:
water clear single color red
High bright output
Low power consumption
High reliability and long life/light decal very slow..
Descriptions:
Dice material:GaInN
Emitting Color:Super Bright white
Device Outline:φ5mm Round Type
Lens Type:Water Clear
Specification:
1.Flux: 25000~28000mcd
2.Wavelength: 588-594nm
3. Forward Voltage: 3.0-3.4V
4.Beam Angle:120degree around
| 4.8mm helmet led | ||||
| Part No. | Intensity | Angle (Degree) | CCT available | Voltage( V) |
| FD-5HTW-1 | 1800-2000mcd | 100-120deg | From 2500 to 20000K | 3.0-3.4V |
| FD-5HTW-2 | 2000-2500mcd | 100-120deg | 3.0-3.4V | |
| FD-5HTW-3 | 2500-3000mcd | 100-120deg | 3.0-3.4V | |
| Part No. | Color | Angle (Degree) | Wavelength | Voltage( V) |
| FD-5HTR-1 | Red | 100-120deg | 620-625nm | 1.9-2.4V |
| FD-5HTY-1 | Yellow | 100-120deg | 588-595nm | 1.9-2.4V |
| FD-5HTG-1 | Green | 100-120deg | 520-525nm | 3.0-3.4V |
| FD-5HTB-1 | Blue | 100-120deg | 460-470nm | 3.0-3.4V |
| 4.8mm Straw hat led | ||||
| Part No. | Intensity | Angle (Degree) | CCT & Wavelength | Voltage( V) |
| FD-5STW-1 | 1800-2000mcd | 100-120deg | From 2500 to 20000K | 3.0-3.4V |
| FD-5STW-2 | 2000-2500mcd | 100-120deg | 3.0-3.4V | |
| FD-5STW-3 | 2500-3000mcd | 100-120deg | 3.0-3.4V | |
| Part No. | Color | Angle (Degree) | Itensity | Voltage( V) |
| FD-5STR-1 | Red | 100-120deg | 620-625nm | 1.9-2.4V |
| FD-5STY-1 | Yellow | 100-120deg | 588-595nm | 1.9-2.4V |
| FD-5STG-1 | Green | 100-120deg | 520-525nm | 3.0-3.4V |
| FD-5STB-1 | Blue | 100-120deg | 460-470nm | 3.0-3.4V |
|
5mm round Red color in water clear lens |
||||
| Viewing angle in 15-20degree | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TR-1 | 4000-6000 | 15-20 | 620-630 | 1.9-2.4 |
| FD-5TR-2 | 6000-8000 | 15-20 | 620-630 | 1.9-2.4 |
| FD-5TR-3 | 8000-12000 | 15-20 | 620-630 | 1.9-2.4 |
| FD-5TR-4 | 12000-18000 | 15-20 | 620-630 | 1.9-2.4 |
| FD-5TR-5 | 18000-20000 | 15-20 | 620-630 | 1.9-2.4 |
| FD-5TR-6 | 20000-23000 | 15-20 | 620-630 | 1.9-2.4 |
| FD-5TR-7 | 23000-25000 | 15-20 | 620-630 | 1.9-2.4 |
| 5mm round Yellow color in water clear lens | ||||
| Viewing angle in 15-20degree | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TY-1 | 5000-7000 | 15-20 | 588-595 | 1.9-2.4 |
| FD-5TY-2 | 8000-10000 | 15-20 | 588-595 | 1.9-2.4 |
| FD-5TY-3 | 10000-15000 | 15-20 | 588-595 | 1.9-2.4 |
| FD-5TY-4 | 18000-22000 | 15-20 | 588-595 | 1.9-2.4 |
| FD-5TY-5 | 22000-25000 | 15-20 | 588-595 | 1.9-2.4 |
| 5mm round Amber color in water clear lens | ||||
| Viewing angle in 15-20degree | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TA-1 | 5000-7000 | 15-20 | 600-610 | 1.9-2.4 |
| FD-5TA-2 | 8000-10000 | 15-20 | 600-610 | 1.9-2.4 |
| FD-5TA-3 | 10000-15000 | 15-20 | 600-610 | 1.9-2.4 |
| FD-5TA-4 | 18000-22000 | 15-20 | 600-610 | 1.9-2.4 |
| FD-5TA-5 | 22000-25000 | 15-20 | 600-610 | 1.9-2.4 |
| 5mm round Whitecolor in water clear lens | ||||
| Viewing angle in 15-20degree | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TW-1 | 13000-16000 | 15-20 | Warm white (2500-5500K) Pure white (5500-6500K) Cool white (6500-10000K) | 3.0-3.4 |
| FD-5TW-2 | 16000-18000 | 15-20 | 3.0-3.4 | |
| FD-5TW-3 | 20000-23000 | 15-20 | 3.0-3.4 | |
| FD-5TW-4 | 25000 | 15-20 | 3.0-3.4 | |
| FD-5TW-5 | 25000mcd ( Perfect light version ) | 15-20 | 3.0-3.4 | |
| 5mm round Greencolor in water clear lens | ||||
| Viewing angle in 15-20degree | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TG-1 | 20000-23000 | 15-20 | 520-530 | 3.0-3.4 |
| FD-5TG-2 | 23000-25000 | 15-20 | 520-530 | 3.0-3.4 |
| FD-5TG-3 | 25000-28000 | 15-20 | 520-530 | 3.0-3.4 |
| FD-5TG-4 | 28000 Perfect light version | 15-20 | 520-530 | 3.0-3.4 |
| 5mm round Bluecolor in water clear lens | ||||
| Viewing angle in 15-20degree | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TB-1 | 6000-8000 | 15-20 | 460-470 | 3.0-3.4 |
| FD-5TB-2 | 10000-15000 | 15-20 | 460-470 | 3.0-3.4 |
| FD-5TB-3 | 13000-15000 | 15-20 | 460-470 | 3.0-3.4 |
| FD-5TB-4 | 15000-18000 | 15-20 | 460-470 | 3.0-3.4 |
| 5mm round Purple color in water clear lens | ||||
| Part No. | Intensity at 20mA ( mcd ) | Emitting Angle ( Degree ) | Wavelength ( nm ) | Voltage ( V ) |
| FD-5TUV-1 | 2000-3000 | / | 400-410 | 3.0-3.4 |
| FD-5TUV-2 | 3000-5000 | / | 400-410 | 3.0-3.4 |
| FD-52TUV-1 | 1500 | / | 390-400 | 3.0-3.4 |
| FD-53TUV-1 | 800 | / | 380-385 | 3.0-3.4 |
| FD-54TUV-1 | 300 | / | 365 | 3.0-3.4 |
| FD-55TUV-1 | 1000 | / | 410-420 | 3.0-3.4 |
| FD-356TUV-1 | 800 | / | 430-440 | 3.0-3.4 |
