2, 90-265v input
3, 5v,12v, 24v output
4, 100% full load aged
5, lower cost but higher quality
150w swtich power supply constant voltage 12v/24vdc output for led display, led strip etc and security power supply
OEM and ODM service is available and tech support for your circult and light source design
| Model Number | TS-SP-150W |
| Place of Origin | China |
| Brand Name | tresun |
| Output Power | 150W |
| Output Type | Single |
| Input Voltage | 85-265vac |
| Output Voltage | DC12V/24v |
| Output Frequency | 50-60Hz |
| Output Current | 12.5A, 6.2A |
| Power Factor | 0.6-0.95 (optional) |
| Application | led strip, module, display etc |
| Color | Silver |
| Material | Aluminum |
| Size | 199x98x38mm |
| IP Rating | non waterproof |
| Lifespan | 30,000-50,000 hours |
| Warranty | 2 years |
| Certificate | CE, RoHS |
Feature
.Non waterproof Constant voltage power supply 150w 5v/12v/24v from tresun
.International full-range input voltage
·Protection: shortcircuit/overload/overvoltage/overheat
·Natural air cooled
·100% full load aged
·Idle power < 1.1W
·All capacitors are 105°C long-life electrolytic
·Capacity of surge of 300VAC: 5 seconds
·Working temperature up to 70°C
·Passes 5G vibration test, 150W 12.5A power supply for strips, modules, industrial usage
·High efficiency, long life & high reliability
·High quality, high efficiency>85%
·Non waterproof, inside use
.With CE certificate, complied RoHS standard
·Over-heat, short-circuit & over-load protection with self-setting
·Rigorous ripple and low noise
·2-year warranty for 150W power supply 12v/24v constant voltage output
Very lower cost and fast delivery, wholesale and ship from factory, feel free to constact us today, sample and datasheet are available upon requested
