Product type: Constant Voltage Drive
Application Scope: LED Lamps, LED Spotlights, LED Grille, LED PAR Lamp
Product size: Size: 95mm(L)×70mm(W)×32mm(H)
Warranty: 3 years
Quick Details
- Place of Origin: Henan, China (Mainland)
- Brand Name: tresun/oem
- Model Number: LZV40W-12
- Output Power: 1 - 50W
- Output Type: Single
- Input Voltage: 90-305vac
- Output Voltage: 12Vdc
- Output Frequency: 47-63Hz
- Output Current: 3330mA
- Watperproof: Yes, IP67waterproof
- Efficiency: 85%">>85%
- Quality: High quality ecap and original chip
- Customized: Voltage, current, brand, size can be customized
- Size: 95x70x32mm
- Output current: 3330mA
- Output voltage: 12v
- Output current max: 3.33A
| Constant Voltage |
Input Voltage Vac |
Power Factor |
Output Voltage Vdc |
Constant Max mA |
Voltage Acuracy % |
Typical Efficiency | Location | CQC | CE | |
| LZV40W Series | @120v | @230v | ||||||||
| LZV40W-114 | 90-305 | 0.99 | 0.95 | 114 | 350 | ±5 | 89 | Indoor | yes | Yes |
| LZV40W-100 | 90-305 | 0.99 | 0.95 | 100 | 400 | ±5 | 88 | Indoor | Yes | Yes |
| LZV40W-89 | 90-305 | 0.99 | 0.95 | 89 | 450 | ±5 | 88 | Indoor | Yes | Yes |
| LZV40W-54 | 90-305 | 0.99 | 0.95 | 54 | 700 | ±5 | 88 | Indoor | Yes | Yes |
| LZV40W-48 | 90-305 | 0.99 | 0.95 | 48 | 830 | ±5 | 88 | Indoor | Yes | Yes |
| LZV40W-36 | 90-305 | 0.99 | 0.95 | 36 | 1100 | ±5 | 88 | Indoor | Yes | Yes |
| LZV40W-30 | 90-305 | 0.99 | 0.95 | 30 | 1300 | ±5 | 87 | Indoor | Yes | Yes |
| LZV40W-24 | 90-305 | 0.99 | 0.95 | 24 | 1670 | ±5 | 86 | Indoor | Yes | Yes |
| LZV40W-22 | 90-305 | 0.99 | 0.95 | 22 | 1820 | ±5 | 85 | Indoor | Yes | Yes |
| LZV40W-18 | 90-305 | 0.99 | 0.95 | 18 | 2200 | ±5 | 85 | Indoor | Yes | Yes |
| LZV40W-15 | 90-305 | 0.99 | 0.95 | 15 | 2680 | ±5 | 85 | Indoor | Yes | Yes |
| LZV40W-13 | 90-305 | 0.99 | 0.95 | 13 | 3080 | ±5 | 84 | Indoor | Yes | Yes |
| LZV40W-12 | 90-305 | 0.99 | 0.95 | 12 | 3330 | ±5 | 83 | Indoor | Yes | Yes |
| LZV40W-10 | 90-305 | 0.99 | 0.95 | 10 | 4000 | ±5 | 83 | Indoor | Yes | Yes |
| LZV40W-09 | 90-305 | 0.99 | 0.95 | 9 | 4450 | ±5 | 82 | Indoor | Yes | Yes |
Product details:
LZV40W Series, led constant voltage drivers
1. Drive Mode: Constant Voltage
2. Technology: Single-stage PFC technology
3. Output Power: 40W Max.
4. Input Voltage: 100 to 277VAC,47-63HZ
5, Number of output: single
6. Output Voltages: 9~ 114Vdc
7. Output Currents: 350mA - 4450mA
8. Safety: EN61347, J61347 (H20), UL8750, CSA C22.2
9. EMC: EN55015, J55015 (H20), FCC 47CFR Part 15 Class B
10. Comply with PSE, CE & CCC
11. RoHs compliant;
12. Plastic Shell, Silicone Potting, Up to 120°C;
13. Compact, Lightweight Design;
14. Water Resistant and Dust Proof Design: IP66, NEMA 13, for Dusty, Damp, Wet Locations;
15. Standard electrical box for installation;
16. Active Power Factor Correction technology to reduce power consumption;
17. Safety Isolation between Primary and Secondary.
18. Surge Immunity (Lightning Protection): Comply with EN61000-4-5, AC line to line 1000V
Product parameters:
1. Operating Temperature: −30 to +60°C,
2. Storage Temperature: −40 to +85°C;
3. Humidity (non-condensing): 5% to 95%RH;
4. Cooling: Convection;
5. Vibration Frequency: 5 ~ 55HZ/2g, 30 minutes;
6. Impact Resistance: 1g/S;
7. MTBF@40°C: 540,000 hours @ Full Load per MIL-217 Notice 2.;
8. LIFE@25°C: 120,000 hours @ Full Load per MIL-217 Notice 2.;
9. Maximum Input Current: 0.15A (@ 120V, full load);
10. Input Surge Current: <15A (25°C, 230V, cold start);
11. CISPR 22 CLASS B, CISPR 14-1 CLASS B,
EN61000-3-2 & EN61000-3-3 Class C,
GB19510.14-2009, GB19510.1-2009,
GB17743.1-2007, GB17625.1-2003
12. Constant Current Regulation: ±3%, Over Input Line Variation;
13. Load Regulation Accuracy: ±3%;
14. Output Current Ripple: < 1%*Vo ;
15. Leakage Current: 400uA typical; Hold up time: half cycle
16. Standby Power: <0.4W@120V, <0.8W@230V, <1.0W@277V;
17. Protection: Output over-voltage protection;
Output over-current protection;
Output short circuit, auto-recovery;
18. Lightning & transient protection built in.
