2, 90-265v input, 30-36v output
3, 10-18x1W, non waterproof
4, 100% full load aged
10-18x1W led driver constant current 300mA for ceiling light, panel light wall light etc outside power supply
OEM and ODM service is available and tech support for your circult and light source design
| Model Number | TS-OD-10-18x1W |
| Place of Origin | China |
| Brand Name | tresun |
| Output Power | 10-18w |
| Output Type | Single |
| Input Voltage | 85-265vac |
| Output Voltage | DC30-36V |
| Output Frequency | 50-60Hz |
| Output Current | 300mA |
| Power Factor | 0.6-0.95 (optional) |
| Application | for ceiling light, downlight, panel |
| Color | Silver or Grey |
| Material | Aluminum, PC |
| Size | 700x34x26.5mm |
| IP Rating | non waterproof, dustproof |
| Lifespan | 30,000-50,000 hours |
| Warranty | 2 years |
| Certificate | CE, RoHS |
Feature
.Non waterproof Constant Current LED Driver 300mA 10w, 11w, 12w,13w, 14w, 15w, 16w, 17w, 18w from tresun
.International full-range input voltage
·Protection: shortcircuit/overload/overvoltage/overheat
·Natural air cooled
·100% full load aged
·Idle power < 1.1W
·All capacitors are 105°C long-life electrolytic
·Capacity of surge of 300VAC: 5 seconds
·Working temperature up to 70°C
·Passes 5G vibration test, 300mA power supply outside
·High efficiency, long life & high reliability
·High quality, high efficiency>85%
·Non waterproof, dustproof
.With CE certificate, complied RoHS standard
·Over-heat, short-circuit & over-load protection with self-setting
·Rigorous ripple and low noise
·2-year warranty for 10-18x1w led driver 300mA constant current for outside use power supply
Very lower cost and fast delivery, wholesale and ship from factory, feel free to constact us today, sample and datasheet are available upon requested
