Input Voltage: 90-265Vac
Output Voltage: 25-45Vdc
Output Frequency: 50-60Hz
Output Current: 600mA
Watperproof: Yes, IP67waterproof
Efficiency: >85%
Specifications
1, 20W constant current led driver 2, 90-265Vac input 3, 600mA, 25-45v output 4, 100% burn-in test 5, 2 year warranty20w led driver constant current waterproof 600mA 25-45vdc output wholesale from factory
Feature
Waterproof Constant Current LED Driver from tresun
.International full-range input voltage
·Protection: shortcircuit/overload/overvoltage/overheat
·Natural air cooled
·100% full load aged
·Idle power < 1.1W
·All capacitors are 105°C long-life electrolytic
·Capacity of surge of 300VAC: 5 seconds
·Working temperature up to 70°C
·Passes 5G vibration test, 12W, 15W, 18W, 20W driver
·High efficiency, long life & high reliability
· High quality, high efficiency>85%
· Waterproof, dustproof, IP67
· With CE certificate, complied RoHS standard
· Over-heat, short-circuit & over-load protection with self-setting
· Rigorous ripple and low noise
·2-year warranty for 20w led driver 600mA constant current
| Model Number | LZ220V20W8-12S2P |
| Place of Origin | China |
| Brand Name | tresun |
| Output Power | 20W |
| Output Type | Single |
| Input Voltage | AC 90-265V |
| Output Voltage | DC 25-45V |
| Output Frequency | 50-60Hz |
| Output Current | 600mA |
| Power Factor | 0.7-0.95 (optional) |
| LED Connection Type | high power led 8-12 series and 2 parallel |
| Color | Silver or Grey |
| Material | Aluminum |
| Size | 105x35x23mm |
| IP Rating | IP67, waterproof, dustproof |
| Lifespan | 30,000-50,000 hours |
| Warranty | 2 years |
| Certificate | CE, RoHS |
