DC-HSPA+ (DL) data service of up to 43.2 Mbit/s
uawei E5186 4G LTE CPE Technical Specifications:
* LTE Category 6 Wireless Router/Gateway
* Technical Standards: LTE/DC-HSPA+/HSPA+/HSPA/UMTS/EDGE/GPRS/GSM
* Download Speed up to 300mbps, upload speed to 50Mbps
* Huawei E5186s-22a: LTE Band 1/3/7/8/20/38 (FDD 800/900/1800/2100/2600MHz, TDD 2600MHz)
* Huawei E5186s-61a: LTE Band 3/7/28/40 (FDD 700/1800/2600MHz TDD 2300MHz)
* DC-PA+/HSPA+/UMTS 900/2100MHz
* GSM/GPRS/EDGE 850/900/1800/1900MHz
* LAN: IEEE 802.3/802.3u, IEEE 802.11a/b/g/n/ac
* WLAN(Indoor use only): 2.4GHz(2.400GHz-2.474GHz)/5GHz(5.150GHz-5.825GHz)
* Support up to 64 devices through WiFi
* Interface: - One power port - Two RJ11 ports for telephone connections - Three Gigabit Ethernet RJ45 ports for LAN connections - One Gigabit Ethernet RJ45 for both LAN and WAN connections - One USB 2.0 host port - One Micro subscriber identity modules(SIM)card port - Two External Antenna ports
* Buttons: - One power switch - One WiFi button - One WPS button - One Reset button
* Power consumption: <20W
* Power supply: AC: 100-240V / DC: 12V/2A
* Firewall, CS Voice, VoIP, VoLTE, TR069 Remote Management
* HTTP Online Upgrade, QoS, USB Share, UPnP
* IPV6, DLNA, Fax, Print, VPN
* Temperature Working temperature: 0°C to +40°C
* Storage temperature: –20°C to +70°C
* Humidity: 5%–95% RH
* Dimensions(H x W x D): 190 mm × 200 mm × 32 mm
* Weight: About 518 g
