Product Name:
Outdoor wifi Router 5G CPE Win H312-371 General Specifics:
Huawei 5G CPE Win H312-371 outdoor routerThe HUAWEI 5G CPE H312-371 is a 5G wireless gateway for multiple users in household or small office environments. It enables users to access the Internet.
Product Details:
Huawei 5G CPE Win H312-371 Specifications:
Product type: 5G outdoor CPE
1, Chipset: Huawei 5G Balong 5000 chipset
2, Communication Standard: 3GPP Release 15
3, Network Mode: NSA / SA(*SA capabilities depend on the available network and software version, which need to be customized.)
4, Support 5G Frequency Band: n41/n77/n78/n79
5, 5G Transmission Rate: 1.65Gbps / 250Mbps (Theoretical value. The peak rate depends on the operator and the Ethernet port)
6, 4G Transmission Rate: 1.6Gbps / 150Mbps (Theoretical value. The peak rate depends on the operator and the Ethernet port)
7, Wireless Frequency Band: 2.4GHz, only for installation and configuration, not for internet access
8, Antenna
- 5G / 4G Antenna Type: 5G / 4G main and diversity antennas
- WLAN Antenna Type: Built-in 2.4GHz Wi-Fi antenna
9, Network Port: 1 GE Lan port, 1 SIM card slot (Nano-SIM)
10, Button: Reset
11, Led Indicator: 5G / 4G indicator
12, Power Supply: < 24W
13, AC/DC Power Supply: AC: 100V - 240V 50Hz/60Hz, DC: 19V/1.26A
14, HUAWEI AI Life App: Mobile network (5G / 4G) access, Ethernet access, SMS service, firewall, PIN protection, MAC address filtering, Wi-Fi encryption authentication, VPN tunnel / VPN penetration, IPv6 and IPv6 / IPv4 dual stack, multi-APN, WebUI, HOTA, etc
15, Operating temperature: -40 °C ~ 55 °C (no solar radiation), storage temperature: -40 °C ~ + 70 °C
16, Humidity: 5% ~ 95% (non-condensing)
17, Easy to install on windowsill/wall/pole for better signal
18, IP65 Waterproof and dustproof
19, Support POE(Power Over Ethernet)
20, Dimensions: 187mm(Depth) x 112mm(Height) x 29.6mm(Width)
21 Weight: About 570g (excluding the power adapter)
* Working band: 5G: n41/77/78/79(4800MHz~5000MHz),
LTE: B1/3/5/7/8/18/19/20/28/32/34/38/39/40/41/42/43 * *Wi-Fi: 2.422 GHz~2.482 GHz,Wi-Fi is used only for user installation and configuration. If the user accesses the Internet through this Wi-Fi, the performance cannot be guaranteed. First connect the indoor router to the H312-371 and then connect the Wi-Fi of the indoor router to access the Internet.
1 GE port for LAN.
Multi APN function (Optional) for Data
TR-069 services(Optional)
Routing mode: NAT enable (Default) / IP pass-through (Optional)
VPN client service (L2TP, PPTP)
Customer management via WebUI or HUAWEI AI Life APP (Android)
Operator maintenance via TR-069 (Optional) and TR-143 (Optional)
Huawei Firmware Over the Air (HOTA)
