Support 4G LTE CAT4 LTE-FDD and LTE-TDD
Multiple Fast Ethernet Port, 1 WAN 3 LAN Ethernet Connection
1200Mbps Dual Band WiFi, More Wireless Speed and Better Coverage
Omni-Directional High Gain 4G I
e ComFi C120 4G LTE WiFi Router / CPE (Customer Premise Equipment) provides superior wireless access
performance and comprehensive routing capabilities to bring wireless broadband data and 4G voice services to endusers. It converts high-speed LTE FDD/TDD signal to Wi-Fi signals on the local area network (LAN) and Wireless LAN
(WLAN). Wireless and wired devices which including mobile phones, laptops, tablets, printers, IP cameras and other
smart devices, can access the ComFi C120 4G LTE WiFi Router / CPE simultaneously.
4G/3G/2G Technical Specifications
Cellular Technology LTE FDD, LTE-TDD, WCDMA, TD-SCDMA, EDGE, GPRS, GSM
Data Rate LTE-FDD: Max 150Mbps DL / Max 50Mbps UL LTE-TDD: Max 130Mbps DL / Max 35Mbps UL WCDMA: Max 21Mbps DL / Max 5.76Mbps UL TD-SCDMA: Max 4.2Mbps DL / Max 2.2Mbps UL EDGE: Max 236.8Kbps DL / Max 118Kbps UL GPRS: Max 85.6Kbps DL / Max 85.6Kbps UL GSM: Max 9.6Kbps DL / Max 2.7Kbps UL
Rx Sensitivity Compliance with 3GPP Release 9 Standard
Tx Output Power (Max) LTE-FDD: 23dBm±2dB LTE-TDD: 23dBm±2dB WCDMA: 24dBm±1dB/-3dB TD-SCDMA: 24dBm±1dB/-3dB GSM: B5/B8: +33±2dB (Power Class 4) GSM: B2/B3: +30±2dB (Power Class 1)
Antenna Type Internal Antenna (For C120 / C120V/ C120B / C120VB Model) External Detachable Antenna (For C120E, C120EV, C120EB, C120EVB Model)
Antenna Gain 2~3dBi
