Product Name:
Desktop huawei router b311-221 supports 4G vpn Lite General Specifics:
new 4g cpe router huawei b311-221 with rj11 phone portThe HUAWEI LTE CPE B311-221 is a Long Term Evolution (LTE) wireless gateway for multiple users in household or small office environments. It enables users to access the Internet.
The B311-221 suppor
Product Details:
The supported service functions of b311-221 are as follows:
1, Data service up to DL 150Mbps (64QAM) and UL 50Mbps (16QAM)
2, Working band: LTE: B1/3/7/8/20/38, UMTS: B1/B8, GSM: B2/B3/B5/B8
3, Voice service: CS/ VoIP (Optional) / VoLTE (Optional)
4, Wi-Fi: 2.4 GHz 802.11b/g/n 2x2 MIMO up to 300Mbps. Maximum Users: 32
5, 1 GE port for LAN/WAN
6, Multi APN function (Optional) for Data, Voice (VoIP), TR-069 services
7, Routing mode: NAT enable (Default) / IP pass-through (Optional)
8, VPN client service (L2TP, PPTP)
9, Customer management via WebUI or HUAWEI SmartHome APP (iOS or Android)
10, Operator maintenance via TR-069 (Optional) and TR-143 (Optional)
11, Huawei Firmware Over the Air (HOTA)
The B311-221is a household wireless broadband access product designed for use in scenarios with relatively few network access devices and relatively low network reliability requirements, such as homes or small office and home offices (SOHOs).
The B311-221 is not an enterprise-grade product. It cannot be used by medium- or large-sized enterprises or in scenarios with high network reliability requirements, such as banks, securities agencies, traffic control, and communications device backhaul.
The B311-221 has the following constraints:
1, When the IP Pass-Through mode is enabled, the HOTA function cannot be used.
2, When the L2TP/PPTP VPN client function is enabled, the throughput performance will slow down.
3, A maximum of 32 devices can be connected to the WLAN in theory; the actual number of devices that can be connected and served depends on actual conditions.
B311-221 other features:
1, LTE access function: The B311-221 adopts the LTE access technology at the WAN side.
2, LAN access function: One 10/100/1000 Mbps high-speed Ethernet ports are provided at the LAN side. The B311-221 provides the switching function for local networking and sharing of the broadband network when it is connected to terminal devices.
3, AP function: An 802.11b/g/n-compliant WLAN AP interface is provided for wireless networking at home. The interface is compliant with the IEEE 802.11b/g/n standard and the WEP, WPA/WPA2-PSK, WPA2-PSK security authentication mechanisms.
4, DHCP/DNS: The DHCP server dynamically allocates IP addresses to PCs.
5, Web-based management: You can configure the B311-221 and modify and view the configuration of the B311-221.
6, IP routing protocol and NAT: The B311-221 has high-speed routing capability. With the built-in NAT, the B311-221, together with LTE terminals, can provide flexible broadband access solutions and networking schemes.
