Huawei 4G Router Lite is a new 4G Wireless Router with Ethernet ports and connectors for external antenna. It looks similar to the predecessor model Huawei B310 and B315. Huawei 4G Router Lite can achieve do
Huawei B311As-853 Supports:
* 4G LTE: B1/B3/B5/B8/B26/B28/B34/B38/B39/B40/B41(B41: 2545~2655),
* 3G UMTS: B1/B5/B8 & TD-SCDMA: B34/B39
Technical specifications of the B311-521 main unit
| Item | Description of B311-521 | |
| Technical standard | WAN | 3GPP Release 9 |
| LAN | IEEE 802.3/802.3u | |
| WLAN | IEEE 802.11b/g/n | |
| Working band/frequency | LTE | B2/B4/B5/B7/B28/B66 |
| UMTS | B2/B4/B5 | |
| WLAN | 2.402 GHz~2.472 GHz | |
| External port | 1, One power adapter port 2,One LAN/WAN port (RJ45), IEEE 802.3/802.3u 3, One phone port (RJ11) 4, One external LTE antenna ports (SMA) 5, One SIM card slot (Mini-SIM) |
|
| Antennas | 1, Built-in LTE/UMTS primary antenna 2, Built-in LTE/UMTS secondary antenna 3, Built-in WLAN 2.4 GHz antenna |
|
| Led Indicators | 1, One power indicator (White) 2, One Internet status indicator Cyan: LTE network accessed Blue: UMTS network accessed Green: Ethernet network accessed Red: No SIM card is inserted or detected, or the SIM card has insufficient balance 3, One Wi-Fi/WPS/Hi indicator (White) Flash slowly: A pairable HiLink device is detected. Flash quickly: HiLink pairing is in progress. Off: Wi-Fi is disabled |
|
| AC/DC power supply | AC (input): 100V-240V 50Hz/60Hz DC (output): 12V/1A |
|
| Dimensions (Maximum) | 181 mm (Width) x 126 mm (High) x 36 mm (Deep) | |
| Weight | About 218 g (excluding the power adapter) | |
| Certification/Co mpliance | FCC certification Wi-Fi certification |
|
