A. Introduction

ZTE MF61 WiFi hotspot is a 3.5G mobile hotspot device, working in GSM/GPRS/EDGE/WCDMA/HSPA+ network. The client device could connect to it via USB or Wi-Fi interface. With HSDPA 21Mbps downlink, quad-band GSM and tri-band UMTS, it gives maximum 8 users super fast Internet experience all over the world at the same time.

It runs on battery and has a mini USB port and a built-in OLED display on the top and could supports up to 32GB Micro SDHC memory. The device supports data and SMS services, enabling you to communicate anytime and anywhere.

B. Highlight

* This HSDPA device is peak rated at 21 Mbps downlink speed.

* Operates on the 3G networks for wireless access to e-mail and internet on the move.

* Use 802.11b/g Wi-Fi connection so no installation is required. Simply enter the password key supplied and get on line immediately with your Next G SIM.

* Small, light weight design.

* Supports three working modes: USB Mode, Wi-Fi Mode, Mixed Mode.

Data service:

* HSDPA/HSUPA/UMTS 850/1900/2100 MHz

* GSM/GPRS/EDGE 850/900/1800/1900 MHz

* HSPA+: DL 21.6Mbps, UL 5.76Mbps

* WCDMA CS: 64Kbps UL/DL

* WCDMA PS: 384Kbps UL/DL

C. Interface: USB and Wi-Fi

* Wi-Fi Standard: 802.11b/g/n

* Wi-Fi Security: WEP/WPA/WPA2/WAPI

* USB Version: USB 2.0 high speed

* USB Interface Type: Micro USB

* MicroSD card: ZTE MF60 supports up to 32GB microSD card

D. Battery

* Power Adapter: 5V/700m A Battery: 1500mAh

* Standby time: 100 hours

* Working time: 4 hours

E. Features

* Weight: 77g

* Dimensions(W x h x D): 99.7mm*53.7mm*13.9mm

Notes:

1. MocroSD is a trademark of SD Card Association

2. The ZTE MF60 hotspot’s standby and working time are only for you reference, and based on ideal working environment.
